HPL 93729 LL 750 W 230 V
Product family features
- Operation at mains voltage: 230 V | 240 V
- Color temperature: 3,200 K (for professional film and TV work)
- Color temperature: 3,400 K (for maximum luminous efficacy)
Areas of application
- Stage & Theatre
- Studio, TV, & Film
- Professional Photography
- Club & Disco
Safety advice
To prevent personal injury or damage to property, halogen lamps may only be operated in suitable luminaires designed with suitable mechanisms (protective shields, grids, etc.) to ensure that in the event of a lamp bursting no parts/shards can escape and that during operation no ultraviolet radiation can escape. There must also be a warning sign to indicate that the lamps give off high levels of heat. Detailed information is available on request.
To prevent personal injury or damage to property, halogen lamps may only be operated in suitable luminaires designed with suitable mechanisms (protective shields, grids, etc.) to ensure that in the event of a lamp bursting no parts/shards can escape and that during operation no ultraviolet radiation can escape. There must also be a warning sign to indicate that the lamps give off high levels of heat. Detailed information is available on request.
Technical Data
General Product Information
Global order reference
93729 LL
Product number (Americas)
54670
Product name (Americas)
93729 HPL 750W230V/X 12/CS 1/SKU
Family brand
HPL
General description
750 watt, tungsten halogen, HPL series, long life ,0
ANSI code
Other
Electrical Data
Nominal wattage
750 W
Nominal voltage
230 V
Type of current
AC
Photometric Data
Nominal luminous flux
15600 lm
Useful luminous flux (Φuse)
15595 lm
Φuse value refers to luminous flux
360
Illuminated field
15.5*11.0 mm²
Color temperature
3050 K
Correlated color temperature CCT
3038 K
Chromaticity coordinate x
0.434
Chromaticity coordinate y
0.403
Color rendering index Ra
100
Light center length (LCL)
60.3 mm
Light center length (LCL) - (in)
2.352 in
Physical Attributes & Dimensions
Lamp base
G9.5 w/Hsink
Diameter (in)
0.748 in
Diameter
19.0 mm
Length
104.0 mm
Filament
6-C8
Product weight
57.00 g
Operating Conditions
Burning position
Any
Dimmable
Yes
Lifetime Data
Nominal lifetime
1500 hr
Environmental & Regulatory Information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Primary article identifier
4008321090324
Energy efficiency class
G
Date of declaration
26-06-2024
Declaration no. in SCIP database
In work
Candidate list substance 1
No declarable substances contained
Packaging information
EAN |
Unit |
Piece |
Dimension l x w x h |
Weight |
Volume |
|---|---|---|---|---|---|
| 4008321090324 |
FS
| 1 | 40mm x 40mm x 128mm | 80.00g | 0.20dm³ |
| 4052899246881 |
VS
| 12 | 177mm x 136mm x 152mm | 1160.00g | 3.66dm³ |
Country specific information
EAN |
METEL code |
|---|---|
| 4008321090324 | OSRHPL93729LL |
