TRUCKSTAR LED H7
With the TRUCKSTAR H7 LED, OSRAM's first street-legal1) H7 LED retrofit lamp for 24V vehicles is now on the market.
For truck drivers, fleet managers and freight forwarders. For trucks, special vehicles, buses, and towing vehicles. For nearly everyone in the "heavy duty" sector and beyond. With the street-legal1) TRUCKSTAR H7-LED for 24V Vehicles you can now upgrade the function of your high- and low beam lights of your vehicle to state-of-the-art LED technology. These LED replacement lamps are suitable as a replacement for conventional H7 lamps and bases. They offer a modern and bright white light with a color temperature of up to 6000 Kelvin and impress with up to 230% more brightness2), while the glare of other road users falls below the permissible maximum values by up to 50%2). In comparison to standard lamps, such as halogen lamps, these LED retrofit lamps consume up to 75% less energy and convince thanks to the LED technology and the especially developed and vibration-resistant design, engineered for the 24V and "heavy duty" range, with up to 5 times longer life time3). You can now replace your vehicle lamps with OSRAM´s revolutionary retrofit lamps and experience trend-setting brightness with road approval1) Additionally, OSRAM offers a dedicated guarantee on all TRUCKSTAR LED retrofit lamps4)
Technical Data
Product information
Product legal advice 1
1) Approved LED light source - only applies to the respective countries in which there is approval or to which an equivalent approval applies and the vehicle models and light functions currently listed in the compatibility list. For more details see www.osram.com/nb-led
Product legal advice 2
2) In comparison to the minimum requirements of ECE R112, while the glare is below the maximum permissible values by up to 50%
Product legal advice 3
3) In comparison to traditional Halogen lamps
Application (Category and Product specific)
High and low beam
General Product Information
Global order reference
64215DWTS
Electrical Data
Power input
16.0 W
Nominal voltage
24.0 V
Nominal wattage
16 W
Test voltage
28.0 V
Power input tolerance
±10 %
Photometric Data
Light color LED
Cool white
Color temperature
6000 K
Nominal luminous flux
1500 lm
Luminous flux tolerance
±10 %
Physical Attributes & Dimensions
Product weight
60.00 g
Diameter
13.9 mm
Length
77.9 mm
Lamp base
PX26d
Lifetime Data
Lifespan B3
1500 hr
Lifespan Tc
2500 hr
Capabilities
Technology
LED
Certificates & standards
Standards
ABG
Environmental & Regulatory Information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Primary article identifier
4062172384919
Declaration no. in SCIP database
In work
Packaging information
EAN |
Unit |
Piece |
Dimension l x w x h |
Weight |
Volume |
---|---|---|---|---|---|
4062172384919 |
HFB
| 2 | 140mm x 129mm x 61mm | 247.00g | 1.11dm³ |
4062172384926 |
VS
| 4 | 150mm x 132mm x 142mm | 572.00g | 2.81dm³ |
